HYSYS Flowsheets in 3-4 Days.
Not 3-6 Weeks.
Your process engineers stop spending weeks manually defining unit operations, linking streams, and entering operating conditions from data sheets. Artisan reads your P&IDs and data sheets, maps the process topology, and generates a configured HYSYS flowsheet — ready for your team to run.
Book a DemoArtisan Makes HYSYS
10x Faster to Set Up.
HYSYS is the industry standard for process simulation. The problem isn't HYSYS — it's the weeks your engineers spend manually translating P&IDs and data sheets into a flowsheet before they can even run a simulation. Artisan automates that translation.
From P&ID to Ready-to-Run Flowsheet - Automated.
P&ID Process Topology Extraction
Artisan reads your P&IDs and automatically extracts the process topology — every unit operation, every stream connection, every inlet and outlet. The flowsheet structure is built from your drawings, not typed in manually.
Datasheet & H&MB Parameter Mapping
Operating conditions — temperatures, pressures, compositions, flow rates — are extracted from your datasheets and heat & mass balance sheets and mapped directly to the corresponding streams and unit operations in the HYSYS model.
Automated Stream & Equipment Linking
Every stream connected. Every unit operation defined. Every equipment specification populated. Artisan assembles the HYSYS flowsheet structure from the Contextual Graph — the tedious, error-prone linking work your engineers do by hand, done automatically.
Greenfield & Brownfield Parity
Works for new designs and existing facility models. For greenfield, Artisan generates HYSYS flowsheets from licensor PFDs and datasheets. For brownfield, it reads existing P&IDs and builds the simulation model your facility never had.
Ready-to-Validate Output
Artisan doesn't deliver a black box. It delivers a configured HYSYS flowsheet your process engineers can open, inspect, validate, and refine. Your team stays in control — the AI handles the setup, your engineers handle the engineering.
Direct AspenTech Integration
Artisan generates HYSYS configuration files that plug directly into Aspen HYSYS. No middleware. No data re-entry. No format conversion. The output is native to the tool your process engineers already use every day.
P&ID Process Topology Extraction
Artisan reads your P&IDs and automatically extracts the process topology — every unit operation, every stream connection, every inlet and outlet. The flowsheet structure is built from your drawings, not typed in manually.
Datasheet & H&MB Parameter Mapping
Operating conditions — temperatures, pressures, compositions, flow rates — are extracted from your datasheets and heat & mass balance sheets and mapped directly to the corresponding streams and unit operations in the HYSYS model.
Automated Stream & Equipment Linking
Every stream connected. Every unit operation defined. Every equipment specification populated. Artisan assembles the HYSYS flowsheet structure from the Contextual Graph — the tedious, error-prone linking work your engineers do by hand, done automatically.
Greenfield & Brownfield Parity
Works for new designs and existing facility models. For greenfield, Artisan generates HYSYS flowsheets from licensor PFDs and datasheets. For brownfield, it reads existing P&IDs and builds the simulation model your facility never had.
Ready-to-Validate Output
Artisan doesn't deliver a black box. It delivers a configured HYSYS flowsheet your process engineers can open, inspect, validate, and refine. Your team stays in control — the AI handles the setup, your engineers handle the engineering.
Direct AspenTech Integration
Artisan generates HYSYS configuration files that plug directly into Aspen HYSYS. No middleware. No data re-entry. No format conversion. The output is native to the tool your process engineers already use every day.
"Every HYSYS flowsheet built manually is a project milestone delayed, a process engineer unavailable for higher-value work, and a simulation that could have been running weeks ago. Artisan eliminates this."
Frequently Asked Questions
Common questions about HYSYS flowsheet automation.
No. Artisan automates the setup of HYSYS — it doesn't replace it. Your process engineers still use HYSYS for simulation, optimization, and analysis. What changes is how the flowsheet gets built. Instead of weeks of manual configuration — defining unit operations, linking streams, entering operating conditions — Artisan reads your P&IDs and datasheets and generates the configured flowsheet automatically. Your team opens HYSYS with a model already built, ready to validate and run.
Artisan needs your P&IDs (for process topology — equipment, connections, control loops) and your data sheets or heat & mass balance sheets (for operating conditions — temperatures, pressures, compositions, flow rates). These documents are read as PDFs. No pre-processing, no structured data entry, no manual extraction required. If your facility has P&IDs and data sheets, Artisan can generate the flowsheet.
Yes. HYSYS automation works for both greenfield projects (from licensor PFDs and datasheets) and brownfield facilities (from existing P&IDs and datasheets, regardless of age or format). For brownfield, this is often the first time the facility has ever had a simulation model — built from the engineering documents that have been sitting in filing cabinets for decades.
Artisan generates a configured flowsheet with all streams connected, unit operations defined, and operating conditions populated from your source documents. The output is designed for engineer validation — your team reviews, refines, and approves the model before running simulations. Artisan handles the 90% of setup work that is tedious and error-prone. Your engineers handle the 10% that requires engineering judgment.
3-4 days from P&IDs and datasheets to a configured, ready-to-validate HYSYS flowsheet. Compare that to 3-6 weeks of manual setup. A typical pilot focuses on a single process unit or train — your team sees the generated flowsheet within the first week and validates it against their engineering knowledge. The speed gain is immediate and measurable.
Ready to Get Your HYSYS Flowsheets in Days Instead of Weeks?
Send us your P&IDs and datasheets. See a configured HYSYS flowsheet generated from your own documents — streams connected, conditions populated, ready for your team to validate.
- Generate HYSYS flowsheets in 3-4 days instead of 3-6 weeks.
- Eliminate weeks of manual unit operation definition and stream linking.
- Works for greenfield and brownfield.
- Native Aspen HYSYS output — no middleware, no format conversion.
- Your engineers validate and refine. Artisan handles the setup.
